Danfoss CPCE12 solder capacity regulator 1/2

CPCE Capacity Regulators adapt compressor capacity to actual evaporator load. They are designed for installation in a bypass line between the low and high pressure sides of the refrigeration system for hot gas injection between evaporator and thermostatic expansion valve. Injection should be arranged to occur through an LG liquid-gas mixer. Refrigerants: hcfc and non-flammable hfc refrigerants regulating range 0 - 60 bar (0 – 87 psig) Factory setting 04 bar (58 psig) Max working pressure 28 bar (406 psig) max test pressure 31 bar (450 psig) access port: ¼ in schrader valve for pressure testing Brand:Danfoss Finish:Galvanised Material Type:Ductile Iron Model Number:CPCE12 Warranty:1 Year Refrigerant Suitability:R134a R404A R507 R22 R407C Evaporator Fans:- Danfoss_3_Brochure
