Pegler Yorkshire YP25 reduced branch tee 54 x 54 x 22mm

Tee reduced branch. All ends for copper.- Yorkshire Portable Integral Solder Ring (ISR) capillary fittings in sizes from 6mm to 67mm. contain a ring of high quality lead-free solder. When heat is applied the solder is released into the gap between the tube and the fitting creating a reliable joint without the need for end-feeding additional solder. Suitable for use on hot and cold water services for potable water in small bore and mini bore central heating systems and in low pressure steam heating and pressurised unvented heating systems and in chilled water applications. Also suitable for sanitation services compressed air lines gas distribution systems and engineering pipeline services that convey liquids oils air and gases at temperatures up to 110°C. Kite mark and WRAS Approved Manufactured to bs en 1254 / bs 864 part 2 designed for jointing copper tubes to bs en 1057 (r220 R250 and r290) in a wide range of applications Brand:Pegler Yorkshire Connection Type:Solder Ring Diameter:54mm x 54mm x 22mm Material Type:Copper Model Number:YP25 Operating Temperature:-40°C to 110°C Warranty:25 Years
